DE NEEF® waterproofing injection solutions

Leaks stop here: Fast, proven, durable.

The DE NEEF® portfolio provides waterproofing injection solutions that stop leaks under any circumstances and in any application--foundations, infrastructure and more. Nobody plans for a leak, so when one occurs it usually represents a cost overrun and a setback for a construction project. The ability to quickly and permanently stop a leak in any part of a construction is therefore invaluable for contractors and owners.

Documents

Data Sheets

Product Name Product Data Sheet SDS/MSDS
DE NEEF® Denepox 40
Product Data Sheet
SDS/MSDS
DE NEEF® Gelacryl Superflex AR
Product Data Sheet
DE NEEF® HA CUT AF
Product Data Sheet
SDS/MSDS
DE NEEF® HA Flex LV AF
Product Data Sheet
SDS/MSDS
DE NEEF® HA Flex SLV AF
Product Data Sheet
SDS/MSDS
DENEPOX™ LM
Product Data Sheet
Elastopack 201
Product Data Sheet
SDS/MSDS
Epicol T
Product Data Sheet
GELACRYL™
Product Data Sheet
SDS/MSDS
GELACRYL™ Superflex
Product Data Sheet
SDS/MSDS
HA CUT™ Cat F/XF/SXF AF
Product Data Sheet
SDS/MSDS
HA CUT™ CFL AF
Product Data Sheet
SDS/MSDS
HA SAFEFOAM NF
Product Data Sheet
SDS/MSDS
HA Soil AF
Product Data Sheet
SDS/MSDS
Products & Accessories

Products

  • Product Name
  • Description
  • Key Benefits
  • Applications Type
DE NEEF® Denepox 40
Description

Two-component epoxy resin, which cures into a rigid compound in wet and dry conditions.

Key Benefits
  • Insensitive to humidity.
  • Cures in damp/wet environment.
  • Low viscosity: deep penetration in the cracks.
Application Type
  • Low pressure injection for the structural bonding of cracks and microcracks in dry or wet concrete.
  • Bonding and anchoring.
  • Sealing of porous low density concrete.
  • DE NEEF® Denepox 40 is not suited for applications in contact with moving water.
DE NEEF® Gelacryl Superflex AR
Description

Gelacryl Superflex AR is a 2-component polyacrylate gel. The A-component is a poly-acrylate resin, the B-component is a polymer blend. The 2-components are injected with a 2-component 1:1 ratio piston pump. Once polymerised, Gelacryl Superflex AR forms a resilient, highly elastomeric gel.

Key Benefits
  • Gelacryl Superflex AR injection systems are injected with a twin piston, 1/1 ratio pump.
  • Exceptionally low viscosity. Gelacryl Superflex AR penetrates into cracks 0,1 mm wide.
  • Excellent post-expansion properties in contact with water.
Application Type
  • Curtain grouting.
  • Remedial repair of water leaks.
  • Preventative waterproofing of structures.
  • Water control during tunnelling operations.
  • Waterproofing subterranean structures in concrete or masonry (cellars, underground car parks, etc.).
  • Waterproofing cracks in concrete or rock.
  • Waterproofing tunnel segments.
  • Waterproofing tunnel liners.
  • Expansion joints with small movement.
DE NEEF® HA CUT AF
Description

DE NEEF® HA Cut AF is a next generation 1-component injection resin with improved waterproofing and water cutting performance.

Key Benefits
  • ADR free transport
  • Next generation resin with improved waterproofing performance.
  • Improved cell structure of the cured compound resulting in better mechanical properties and durability.
Application Type
  • Used to block water leaks in diaphragm walls.
  • Filling large voids
  • Injection of LDPE or HDPE membranes in tunnel construction
DE NEEF® HA Flex LV AF
Description

In its uncured form, HA Flex LV AF is a yellow, non-flammable liquid without phthalate plasticisers. HA Flex LV AF is a next generation 1-component injection resin with improved waterproofing performance.

Key Benefits
  • Complies with EN 1504-5, Principle D.
  • ADR-free transport.
  • Next generation resin with improved waterproofing performance.
Application Type
  • For stopping water leaks through joints between tunnel segments.
  • For injection of the LDPE or HDPE membrane in tunnel constructions.
  • For curtain injections behind tunnel segments
DE NEEF® HA Flex SLV AF
Description

In its uncured form, HA Flex SLV AF is a yellow, non-flammable liquid without phthalate plasticisers. HA Flex SLV AF is a next generation 1-component injection resin with improved waterproofing performance.

Key Benefits
  • Next generation resin with improved waterproofing performance.
  • Improved cell structure of the cured compound resulting in better mechanical properties and durability.
  • Non-phthalate resin REACH compliant.
Application Type
  • For stopping water leaks through joints between tunnel segments.
  • For injection of the LDPE or HDPE membrane in tunnel constructions.
  • For curtain injections behind tunnel segments
DENEPOX™ LM
Description

DENEPOX™ LM is a pre-weighted two-component epoxy resin, which cures into a flexible compound. Suitable for applications in dry or wet structures with slight movements, where a flexible product is required.

Key Benefits
  • Insensitive to humidity
  • Cures in damp/wet environment
  • Deep penetration in the cracks
Application Type
  • Bonding
  • Sealing of porous low density concrete
  • Flexible joints in floors
Elastopack 201
Description

Elastopack 201 is a 2-component, phthalate free, injection grout consisting of a resin and a hardener, which are injected as 1-component system after mixing. After curing, the grout will become a dense and elastic material.

Key Benefits
  • ADR free transport
  • Phthalate free resin, REACH compliant
  • Packed as a complete pre-weighted set
Application Type
  • Sealing of moving or non-moving cracks in concrete or masonry structures
  • Sealing of dry to moist cracks in concrete or masonry structures
  • Sealing of hairline cracks where other resins cannot penetrate
Epicol T
Description

2-component sag-free epoxy compound.

Key Benefits
  • Good adhesion to wet surfaces, even for underwater application without the presence of high water pressure.
  • Very good mechanical properties.
  • Cures without shrinking.
  • Easy to mix and use.
  • Adhesion to wood, stone, and concrete; surpasses material cohesion.
Application Type
GELACRYL™
Description

GELACRYL™ is an acrylic-based, hydrophilic gel, consisting of two-components: a resin and an initiator which are pumped with a twin piston pump at a 1/1 ratio. Once polymerised, GELACRYL forms a resilient, elastomeric gel.

Key Benefits
  • Non-flammable
  • No environmental labelling required
  • Poly-acrylate resin, free of acrylamides
Application Type
  • Curtain grouting
  • Sealing of cracks in concrete and rock formations
  • Sealing of tunnel liners
GELACRYL™ Superflex
Description

GELACRYL™ Superflex is a 2-component acrylic based hydrophilic resin, consisting of 2 components: a resin and an initiator which are pumped with a twin piston pump at a 1:1 ratio.

Key Benefits
  • Excellent adhesion to concrete
  • Very good chemical resistance to most acids, alkalis and micro-organisms
  • Polyacrylate resin, free of acrylamides
Application Type
  • Water control during tunnelling operations
  • Curtain grouting
  • Sealing of cracks in concrete and rock formations
HA CUT™ Cat F/XF/SXF AF
Description

HA CUT™ Cat F/XF/SXF AF are red non-flammable, phthalate free liquids for applications in cold temperatures or when use of the standard catalyst does not give a fast enough reaction.

Key Benefits
  • ADR free transport
  • Next generation resin with improved waterproofing performance
  • Improved cell structure of the cured compound
Application Type
  • Cutting off gushing leaks with a high to very high flow rate and/or high to very high pressure
  • Use in cold to very cold temperatures where fast reaction times are needed
HA CUT™ CFL AF
Description

HA CUT CFL AF is a next generation 1- component injection resin with improved waterproofing and water cutting performance.

Key Benefits
  • ADR free transport.
  • Next generation resin with improved waterproofing performance.
  • Improved cell structure of the cured compound
Application Type
  • Designed for cutting off gushing water leaks
  • Used to block leaks into diaphragm walls.
  • Filling large voids
HA SAFEFOAM NF
Description

HA SAFEFOAM™ NF is a single component, phthalate free, low viscosity, hydrophilic, polyurethane resin.

Key Benefits
  • ADR free transport
  • Phthalate free resin, REACH compliant
  • Non-flammable
Application Type
  • For sealing dry, moving, non-structural cracks
  • For sealing moist, moving non-structural cracks
  • For sealing water leaks between the joints of concrete tunnel segments
HA Soil AF
Description

HA SOIL AF is a dark brown, non-flammable, low viscous liquid without phthalate plasticiser that expands and quickly (depending on temperature and the amount of HA SOIL Cat AF catalyst used) cures to a rigid polyurethane foam.

Key Benefits
  • ADR free transport
  • Next generation resin with improved performance
  • Phthalate-free resins, REACH compliant
Application Type
  • Used for stabilising loose soils or to increase the load bearing capacity of these soils.
Overview

Seal leaks almost as fast as they appear

The major advantages of DE NEEF® products include the fact that they are easy to use, are not diluted and can be applied quickly and reliably. The portfolio is mostly based on single-component, closed cell, hydrophobic polyurethanes, which are both durable and lasting. Therefore, leaks that are stopped once will remain stopped. For taking care of leaks that slow down the progress of a job site, endanger the future of a construction, or prevent full use of a building, DE NEEF® has become the world's most trusted brand.

Solutions for every leak

DE NEEF® has a variety of formulations for a number of different applications:

  • For owners who need to repair and maintain buildings and infrastructure projects
  • For contractors who need to shore up deep foundations during excavation
  • For installers and applicators who are charged with specialised leak repair

In every case, there's a DE NEEF® solution that's best-suited for the task at hand—including deep foundations, underground spaces, tunnels, mass rapid transport infrastructure and sewer repair applications.

Solutions for every structure

Concrete or masonry—no matter which type of construction, DE NEEF® can fix the leak. From the ground breaking through completion, DE NEEF® products can be used for soil injections and water control and remediation. DE NEEF® solutions can also be used during excavation or tunnel boring. DE NEEF® products can be used in every stage of underground construction.

Certified around the globe

We have done extensive testing of DE NEEF® products to ensure that performance claims are backed up in the field. DE NEEF® products have multiple certification levels including CE certification for use in the European Union, and have potable water certifications from around the world.

Supported globally, available locally

No two leaks are exactly the same—the only thing that any two leaks have in common is that they have to be fixed as fast as possible. The DE NEEF® portfolio offers solutions for all possible challenges in leak sealing and soil injections. With local availability, there's no waiting for the product to arrive—DE NEEF® is readily available.

With a global sales and technical support staff, contractors can trust that DE NEEF® solutions will perform. Don't wait for leaks to slow you down—contact GCP today to learn how to use DE NEEF® on your project.

Leaks Stop Here. Fast. Proven. Durable.
