BITUTHENE® 8000/8000 HC

Product Advantages

• Water and moisture proof — Provides protection for Grades 2, 3 and 4, BS 8102:1990.

• Gas-resistant — Protects against methane and radon.

• Non-metalised film — Not vulnerable to chemical attack; eliminates overbanding of laps associated with aluminum-based membranes.

• Cold applied — Self-adhesive overlaps ensure continuity.

• Wide application “window” reduces delays — Application temperature ranges from -5ºC to +35ºC (Hot Climate grade is up to 55ºC) and damp surface tolerant.

• Solar reflective surface — Over 20% reduction of solar heat absorption while membrane is temporarily exposed.

• Facilitates quality assured installation — Printed overlap line ensures minimum laps; light colour highlights accidental damage for simple patch repairs.

• Dimension stability — Wrinkle-resistant.

• Chemical resistance — Provides effective external protection against aggressive environment.

• System compatibility — Can be combined with PREPRUFE^® pre-applied membranes, BITUTHENE^® Liquid Membrane, and HYDRODUCT^® drainage composites for system solutions.

Installation

At air temperatures below +4ºC measures should be taken to ensure that all surfaces are free from ice or frost. All surfaces except those below ground bearing slabs should be primed with one coat of Primer B2 / WP-3000 applied at a rate of 8m² (12-15m² for WP-3000) per litre. Bituthene 8000 / 8000 HC Waterproofing Membrane shall be laid by peeling back the protective release paper and applying the adhesive face onto the prepared surface, free from ice, frost or condensation. Bituthene Liquid Membrane to be applied at all internal and external corners, penetrations, etc., prior to applying the overall membrane. Bituthene 8000 / 8000 HC Waterproofing Membrane should be brushed onto the surface to ensure good initial bond and exclude air. Adjacent rolls are aligned using printed lines and overlapped 50mm minimum at side and ends and well rolled with a firm pressure, using a Lap Roller to ensure complete adhesion and continuity between the layers. On high walls it may be necessary to batten fix the membrane to prevent slippage.

Physical Property

_{*Nominal thickness refers to the thickness of the membrane without release liner.
#Run at a rate of 50mm / min.
Note 1: Test carried out on an overlap crossing a post formed
Note 2:    Typical value for BRE recommended minimum standard (BRE Report 212) is 360mL / m² / day.
Typical test values may represent average values from samples tested. Test methods noted may be modified.}

^{Bituthene 8000 Waterproofing Membrane complies with the relevant section of the following national standards: BS 8102:1990. Building Regulations (England and Wales) 1991 (amended 1994) clause C4. Building Regulations (Northern Ireland) 1994 (amended 1995) clause B2. Building Standard (Scotland) Regulations 1990. Regulation B2.1, G2.6.}

Membrane Repairs

Damaged areas to be repaired by patching with an oversized patch applied to a clean dry surface extending 100mm beyond damage and firmly rolled.

^{Details shown are typical illustrations only and not working drawings. For assistance with working drawings and additional technical advice please contact GCP Technical Services.}

^{Comparsion of solar heat gain over time on exposed membrane samples.}

Technical Services

For assistance with working drawings for projects and additional technical advice, please contact your local GCP representative.
